Laser Welding HeadLaser Welding Head

hybird head2 laser beam

1. High-power welding can withstand up to 6kW high-power swing welding 2. Excellent welding quality, low porosity, high mechanical properties, high-quality weld surface 3. Rich scanning graphics, continuous welding supports circular, square, straight, elliptical, C-shaped, S-shaped, 8-shaped 4. Rich expansion modules, expandable temperature sensors, weld tracking or positioning and other functional modules, easy to realize automated welding 5. Drawer-type lens holder protects the lens, which is fast and simple to replace 6. Efficient water cooling, overall circulating water cooling, can work stably for a long time at high power 7. High dustproof Reliable sealing design to improve service life Excellent welding effect

Product Parameters


Power size
≤12kw
Weight
7.5kg
Interface
with Qbh/QD/Q+/LOE Interface
Light aperture
Fiber 35mm + semiconductor 48mm
Laser wavelength
Fiber 1064nm, semiconductor 915/450mm
Collimating Length
F100/125/150/200/280
Focal Length
F250
